16047C Test Fixture

Function and Purpose: Mainly used for impedance evaluation of axial/radial lead devices, and can be used with various instruments such as 4192A, 4194A (impedance mode), 4263A/B, 4268A, 4278A, 4279A, 4284A, 4285A, 4294A, etc. Technical Parameters: Frequency range: DC to 40MHz. Maximum voltage: Maximum ±35V peak (AC + DC). Operating temperature: 0℃ to 55℃. Terminal connections: 4 terminal pairs, BNC. Device under test connection: 2 terminals. Dimensions: Approximately 128 (width) × 26 (height) × 35 (depth) mm.
