N4872A 3.5 Gb/s ParBERT Modules

Overview and Features Data Rate Range: 620 Mb/s to 13.5 Gb/s General Data Range: 620 Mb/s to 13.5 Gb/s Differential and single-ended inputs or outputs Generate and analyze pseudo random word sequences (PRWS), standard PRBS up to 231-1 and memory based patterns up to 64 Mb Generator module Output amplitude/resolution 0.1Vpp - 1.8Vpp /5mV Transition Times (20%-80%): <20ps Jitter: < 9ps pp typ Jitter Modulation bandwidth DC to 1GHz of delay line
