M-UTR80 Manually rotate the displacement stage

OVERVIEW The M-UTR80 precision metric rotary stage is an ideal choice for fine - tuning the angular orientation of any component after rotating it to an approximate angle. The crossed - roller bearings are pre - loaded on a precision optical platform or steel raceway, enabling smooth and precise trajectories with minimal eccentricity. The separated side - mounted clutch knob allows for continuous free rotation of 360 degrees. After obtaining an approximate angular direction through free rotation, a zero - backlash manual drive can provide a 4° fine - adjustment. The scale markings and the vernier on the side of the rotary stage measure the angular position with a minimum resolution of 1 arc. The UTR rotary stage can be installed on the umR series linear stages and other components. It comes with br series clamping devices (including four sets per stage), which are installed on the mounting ring around the base. To install the UTR stage under the umR stage, an adapter is required. In addition, for installation on other positioners and workbenches, the optional PBN base plate or BR - U can be used. The stage can be installed on components through the threaded mounting holes on the bottom surface of the stage. Components can be installed on the top of the 79 - mm - diameter rotary stage through metric threaded holes.
