83496A Optical / Electrical clock recovery module

Overview and Features Optical clock recovery (option 101 only) Inputs & outputs: 9/125 µm (single-mode) to 62.5/125 µm (multimode) Wavelength range: 1250-1650 nm (single-mode), 750-1330 nm (multimode) Minimum optical modulation amplitude: -11 dBm (1310/1550 single-mode), -10 dBm (1310 multimode), -8 dBm (850 multimode) Electrical clock recovery (option 100 only) Inputs: single-ended or differential, 3.5 mm (m) connectors Outputs (option 100 only): single-ended or differential, 3.5 mm (m) connectors Minimum electrical input level: 75 mVpp Continuous unbanded tuning from 50 Mb/s up to 13.5 Gb/s Golden PLL operation (with option 300) with a tunable loop bandwidth from 15 KHz to 10 MHz Ultra low residual jitter: < 300 fs rms (characteristic at 10 Gb/s)
