86103A 2.8 GHz Optical Module / 20 GHz Electrical Module

verview and Features 2.8 GHz optical channel for 9/125 to 62.5/125 fiber Wavelength range: 1000-1600 nm Typical rms noise: 1 μW (155/622 Mb/s), 1.5 μW (1.063/1.250 Gb/s) Reference receiver capabilities (155/622 Mb/s or 1.063/1.250 Gb/s) 20 GHz electrical channel using 3.5 mm male input Typical rms noise: 0.25 mV (12.4 GHz bandwidth), 0.5 mV (20 GHz bandwidth) Maximum input signal: ± 2 Vdc compatibility 86100A/B/C Infiniium DCA/DCA-J Mainframe The Keysight 86103A provides an ideal measurement system for testing SDH/SONET signals at 155 or 622 Mb/s or Fibre Channel at 1063 Mb/s and Gigabit Ethernet at 1250 Mb/s. The calibrated and integrated optical receiver has a bandwidth of more than 2.8 GHz, allowing easy and accurate measurement of single-mode or multimode optical signals. For compliance testing, the hardware filter that supports testing at 155 and 622 Mb/s or 1063 and 1250 Mb/s is automatically switched to form a calibrated reference receiver. This switchable filter maximizes measurement repeatability while minimizing setup time.
